Description
| Frequency (GHz) | DC-4 | 4-8 | 8-12.4 | 12.4-18 |
| Insertion Loss (dB max.) | 0.20 | 0.30 | 0.40 | 0.50 |
| Isolation (dB min.) | 80 | 70 | 60 | 60 |
| VSWR (max.) | 1.2:1 | 1.3:1 | 1.4:1 | 1.5:1 |
| Average Power (Watts Typ.) | 85 | 55 | 45 | 35 |
| Actuating Current (mA max.): | 240 @ 28 Vdc & 20 C |
| Temperature Range (in degrees): | -40 C to +85 C |
| Outline Drawing and Schematic: RMS-4S3AB-I.pdf |
